OWLplane 3D Printed Product Planes
Specification
Wing Loading : 83.3-106.5gr/dm^2.
AUW/Flying Weight : 1800gr-2300gr (with 2200mAh 6s - 3300mAh 6s).
Wing Area : 21.6dm^2.
Wing Cube Loading (WCL) : 17.9-22.9.
Flight Performance Category : Racer.
Radio Channels : Throttle, Aileron and Elevator.
Length : 1040 mm.
Wing Span : 743 mm.
Specification
Wing Loading : 65.6-81.3gr/dm^2.
AUW/Flying Weight : 1050gr-1300gr (with 2200mAh 4s).
Wing Area : 16 dm^2.
Wing Cube Loading (WCL) : 16.4-20.3.
Flight Performance Category : Racer.
Radio Channels : Throttle, Aileron and Elevator.
Length : 867 mm.
Wing Span : 619 mm.
Specification
Wing Loading : 56-64gr/dm^2.
AUW/Flying Weight : 1750gr-2000gr (with 2200mAh 6s).
Wing Area : 31.25 dm^2.
Wing Cube Loading (WCL) : 10-11.4.
Flight Performance Category : Racer.
Radio Channels : Throttle and Elevon.
Length : 1,194.7 mm.
Wing Span : 864.4 mm.
Specification
Wing Loading : 55.0-67.5gr/dm^2.
AUW/Flying Weight : 1100gr-1350gr (with 2200mAh 4s).
Wing Area : 20 dm^2.
Wing Cube Loading (WCL) : 12.3-15.1.
Flight Performance Category : Racer.
Radio Channels : Throttle and Elevon.
Length : 955.75 mm.
Wing Span : 691.5 mm.
Specification
Wing Loading : 82.5-120.3gr/dm^2.
AUW/Flying Weight : 1950-2850gr.
Wing Area : 23.7dm^2.
Wing Cube Loading (WCL) : 16.9-24.7.
Flight Performance Category : Racer.
Radio Channels : Throttle, Aileron, Flap (LG Version) and Elevator.
Length : 1,103mm.
Wing Span : 1,177mm.
Specification
Wing Loading : 92.3gr/dm^2.
AUW/Flying Weight : 1200gr (LW-PLA, with battery 2200mAh 4s).
Wing Area : 13dm^2.
Wing Cube Loading (WCL) : 25.5.
Flight Performance Category : Racer.
Radio Channels : Throttle, Aileron and Elevator.
Length : 817mm.
Wing Span : 872mm.
Specification
Wing Loading : 97.5-112.5gr/dm^2.
AUW/Flying Weight : 1950-2250gr (with battery 2800mAh-3300mAh 6s).
Wing Area : 20 dm^2.
Wing Cube Loading (WCL) : 21.8-25.1
Flight Performance Category : Racer.
Radio Channels : Throttle, Aileron, Flap, Rudder, Nose Steering LG and Elevator.
Length : 1,093 mm.
Wing Span : 994 mm.
Specification
Wing Loading : 65.8-80.8 gr/dm^2.
AUW/Flying Weight : 1750gr-2150gr (with battery 2200mAh 6s).
Wing Area : 26.6 dm^2.
Wing Cube Loading (WCL) : 12.7 to 15.7.
Flight Performance Category : Racer.
Radio Channels : Throttle, Aileron and Elevator.
Length : 1,195mm.
Wing Span : 936mm.
Specification
Wing Loading : 67.6-78.4 gr/dm^2.
AUW/Flying Weight : 1250gr-1450gr (with 2200mAh 4s).
Wing Area : 18.5 dm^2.
Wing Cube Loading (WCL) : 15.7 to 18.2.
Flight Performance Category : Racer.
Radio Channels : Throttle, Aileron and Elevator.
Length : 996mm.
Wing Span : 780mm.
Specification
Wing Loading : 68.4-79.1gr/dm^2.
AUW/Flying Weight : 1,650-1,850gr (with battery 3300mAh 4s to 2200mAh 6s).
Wing Area : 23.4dm^2.
Wing Cube Loading (WCL) : 14.1-16.3
Flight Performance Category : Racer.
Radio Channels : Throttle, Aileron and Elevator.
Length : 1,056mm.
Wing Span : 1,240mm.
Specification
Wing Loading : 66.7-76.7 gr/dm^2.
AUW/Flying Weight : 1,000gr-1,150gr (with battery 1500mAh 4s to 2200mAh 4s).
Wing Area : 15 dm^2.
Wing Cube Loading (WCL) : 17.2 to 19.7.
Flight Performance Category : Racer.
Radio Channels : Throttle, Aileron and Elevator.
Length : 845mm.
Wing Span : 992mm.
Specification
Wing Loading : 88 gr/dm^2.
AUW/Flying Weight : 1650gr (with battery 2200mAh 6s- 400gr).
Wing Area : 18.75 dm^2.
Wing Cube Loading (WCL) : 20.3.
Flight Performance Category : Racer.
Radio Channels : Throttle, Aileron and Elevator.
Length : 1000mm.
Wing Span : 1091mm.
Specification
Wing Loading : 88 gr/dm^2.
AUW/Flying Weight : 1650gr (with battery 2200mAh 6s- 400gr).
Wing Area : 18.75 dm^2.
Wing Cube Loading (WCL) : 20.3.
Flight Performance Category : Racer.
Radio Channels : Throttle, Aileron and Elevator.
Length : 1043mm.
Wing Span : 970mm.
Specification
Wing Loading : 70-95.8 gr/dm^2.
AUW/Flying Weight : 850gr-1150gr (with battery 1500mAh 4s to 2200mAh 4s).
Wing Area : 12 dm^2.
Wing Cube Loading (WCL) : 20.4 to 27.7.
Flight Performance Category : Racer.
Radio Channels : Throttle, Aileron and Elevator.
Length : 800mm.
Wing Span : 873mm.
Specification
Wing Loading : 70-95.8 gr/dm^2.
AUW/Flying Weight : 850gr-1150gr (with battery 1500mAh 4s to 2200mAh 4s).
Wing Area : 12 dm^2.
Wing Cube Loading (WCL) : 20.4 to 27.7.
Flight Performance Category : Racer.
Radio Channels : Throttle, Aileron and Elevator.
Length : 835mm.
Wing Span : 776mm.
Specification
Wing Loading : 65.9 - 79.5 gr/dm^2.
AUW/Flying Weight : 1450 - 1750 gr.
Wing Area : 22 dm^2.
Wing Cube Loading (WCL) : 14 - 17.
Flight Performance Category : Racer.
Radio Channels : Throttle, Aileron, Elevator and Rudder.
Length : 1.013mm.
Wing Span : 1.290mm.
Specification
Wing Loading : 50 - 78.6 gr/dm^2.
AUW/Flying Weight : 1.400 - 2.200 gr (with battery 2200mAh 4s - 2200mAh 6s).
Wing Area : 28 dm^2.
Wing Cube Loading (WCL) : 9.4 - 14.8
Flight Performance Category : Sport Aerobatic.
Radio Channels : Throttle, Aileron and Elevator (Elevon).
Length : 894mm.
Wing Span : 986/1.172mm
Specification
Wing Loading : 81gr/dm^2.
AUW/Flying Weight : 1750gr.
Wing Area : 21.6 dm^2.
Wing Cube Loading (WCL) : 17.41.
Flight Performance Category : Racer.
Radio Channels : Throttle, Aileron and Elevator.
Length : 1,099.2mm.
Wing Span : 843.6mm.
Specification
Wing Loading : 70-80 gr/dm^2.
AUW/Flying Weight : 1050gr-1200gr.
Wing Area : 15 dm^2.
Wing Cube Loading (WCL) : 18.05 to 20.63.
Flight Performance Category : Racer.
Radio Channels : Throttle, Aileron and Elevator.
Length : 916mm.
Wing Span : 703mm.
Specification
Wing Loading : 72.7gr/dm^2.
AUW/Flying Weight : 800gr (with battery 1500mAh 4s).
Wing Area :11dm^2.
Wing Cube Loading (WCL) : 21.8.
Flight Performance Category : Racer.
Radio Channels : Throttle, Aileron and Elevator.
Length : 810mm.
Wing Span : 736mm.
Specification
Wing Loading : 47.1-51 gr/dm^2,
AUW/Flying Weight : 1200 - 1300 gr w/ and w/o Landing Gear respectively,
Wing Area : 25.5 dm^2,
Wing Cube Loading (WCL) : 9.3-10.1,
Flight Performance Category : Sport Aerobatic,
Radio Channels : Throttle, Aileron, Elevator and Rudder,
Length : 1233 mm,
Wing Span : 852 mm.
Specification
Wing Loading : 69.4gr/dm^2,
AUW/Flying Weight : 1250gr (with battery 2200mAh 4s and 64mm EDF),
Wing Area : 18dm^2,
Wing Cube Loading (WCL) : 16.4,
Flight Performance Category : Racer,
Radio Channels : Throttle, Aileron and Elevator,
Length : 972.5mm,
Wing Span : 857.5mm - 1,005mm.
Specification
Wing Loading : 65.2gr/dm^2,
AUW/Flying Weight : 750gr (with battery 1800mAh 4s),
Wing Area : 11.5dm^2,
Wing Cube Loading (WCL) : 19.3,
Flight Performance Category : Racer,
Radio Channels : Throttle, Aileron and Elevator,
Length : 778mm,
Wing Span : 762mm.
